- -41 211,00 Ft
- Új


Garancia: 12 hónap
TYPE
|
MIG-250 | MIG-300 | |
Power supply voltage (V) |
THREE-phase
380V±15%
|
||
Input current (A) Imax | 12 | 17 | |
Power supply capacity (KVA) | 7.9 | 11.2 | |
Current adjustment range (A) | 60-250 | 60-300 | |
Output voltage (V) | 15~26.5 | 15~29 | |
Rated duty cycle (%) | 60 | 60 | |
Power factor | 0.93 | ||
Efficiency (%) | 85 | ||
Wire feeder type | integrated | ||
Water-cooled | no | ||
Post-flow time (s) | 1-2s | ||
Welding wire diameter (mm) | 0.8/1.0/1.2 | 0.8/1.0/1.2/1.6 | |
Package dimension(mm) |
990x650x1010 mm
|
||
Machine dimension(mm) |
875x420x807mm
|
||
Workpiece thickness (mm) | ≥0.8 | ||
Insulation class | F | ||
Protection class | IP21S |
